產品描述
技術參數 SPECIFICATIONS
1、極數CKT:2*1Pin to 2*12Pin
2、額定電流Current rating:5A AC/DC
3、額定電壓Voltage rating(max):250V,AC/DC
4、工作溫度Working Temperature:-25℃~+85℃,
(含通電溫度上升值)
(Including temperature rise in applying electrical current)
5、接觸電阻Contact resistance:初始Initial value ≤20m2
環境測試后After environmental testing ≤30m2
6、絕緣電阻Insulation resistance:≥1000M2
7、耐電壓Withstand voltage:1500VAC(rms)
8、適用線規 Applicable wire:AWG #24 to #20
9、適用基板厚度Applicable PC board thickness:1.6mm to 2.0mm
